AMQ800 is a stable water supply system that integrates pumps, motors,pressuretanks, and electronic controllers. It is suitable forpressurizing clean water withoutimpurities.When in use, the electronic controller controls the start and stop ofthe compressor based on changes in water pressure to provide stable watersupply. The TQ-B series water body is made of antibacterial engineering plasticcontaining silver ions.When positively charged silver ions encounter negatively charged microbial cells,the silver ions penetrate the surface of bacterial cells,damaging their structureand inhibiting bacterial reproduction.
Features
Ultra Energy Saving (Up to 30–50%)
Powered by permanent magnet motor + variable frequency technology, significantly reduces power consumption.
Constant Pressure Comfort
Intelligent VFD control ensures stable water pressure, no fluctuation during use.
Low Noise Operation
Advanced motor design delivers ultra-quiet performance, ideal for homes and villas.
Smart Automatic Control
Auto start/stop based on water demand, improving convenience and system efficiency.
Compact & Integrated Design
Space-saving structure, easy installation, perfect for residential and light commercial use.
Durable & Long Lifespan
High-quality materials and optimized motor reduce wear, ensuring long-term reliability.
Wide Application Range
Suitable for villas, apartments, buildings, hotels, and water supply systems.
Usage conditions
- Ambient temperature: +2°C to +40°C
- Liquid temperature: +2°C to +40°C
- Relative humidity: Max. 85% (RH)
- Operating pressure: Max. 8.5 kg/cm²
- Inlet pressure must be less than starting pressure
Product Parameters
| Voltage | 220V ± 20% | Frequency | 50/60HZ |
| Maximum ambient temperature | 55°C | Rated flow rate | 3m³/h |
| Maximum flow rate | 5m³/h | Maximum current | 3.4A |
| Maximum speed | 5000 ± 200r/min | Rated head | 28m |
| Maximum head | 45m | Maximum suction head | 8m |
| Rated power | 550W | Insulation class | F |
| Maximum system pressure | 1MPa | Fluid temperature | 80C |
| Protection class | IPX5 |
FAQ
Q: Are you a manufacturer or a tradingcompany?
A: We are a comprehensive manufacturer and trader with our own pump production facili-tyin China.You are always welcome tovisit our facilities!
Q: How can l pay you?
A: A:T/T, LC,D/P are all available.
Q: How to use the product?
A: After you receive the product, we will guide you to use or pack it with the product manual.
Q: What about the delivery time?
A: Usually the delivery time is about 10~15 days.Iif you need the product badly, we can discussagain to shorten the delivery time and help ycu get the product as soon as possible.
Q: How long is the warranty period?
A: All products come with a 3-year warranty.
Q: Do you accept custom designs?
A: Yes, we have our own R&D team and can assist with new design products, whether forthe product itself or personalized packaging.
